BIM & Revit Modeling with Clash Detection
Clashes are cheap to fix in a model and expensive to fix on site. We build the models, federate them, and return a clash report your team can actually action.
Concrete deliverables, not vague promises.
Modeling
- Architectural, structural and MEP discipline models
- Modeling from 2D drawings, sketches or point cloud data
- Family and content creation to client standards
- Model development to agreed LOD by element category
Coordination
- Federated model assembly across disciplines
- Clash detection with rule sets tuned to remove noise
- Prioritised, grouped clash reports with viewpoints and screenshots
- Coordination meeting support and issue tracking through resolution
Documentation output
- Sheet sets and coordination drawings generated from the model
- Schedules and quantity extracts
- COBie and asset data exports where required
- 4D sequencing support
2D drawing sets, existing models at any state of completeness, point cloud data, or design sketches. Models inherited from a previous team are welcome: auditing and repairing an inconsistent model is common work.
Codes & standards
ISO 19650 information management, BIMForum LOD specification, and the client's BIM Execution Plan where one exists. Where no BEP exists we'll propose a minimal one before modeling starts, because model conventions agreed late are model conventions applied twice.
Full service engineering design. Delivered remotely.
- 01
Start with a bounded request
Send what you have — sketches, GIS/CAD files, pole data, spreadsheets. A named engineer reviews it and confirms a scoping timetable.
- 02
Agree scope, standards & criteria
Work begins once a written SOW sets deliverables, assumptions, standards and who owns each engineering decision.
- 03
Produce with visible controls
Assumptions, RFIs and progress are logged as they happen, not buried inside the drawing set.
- 04
Independent QA & handoff
A second reviewer checks the package against the SOW before a revision-tracked transmittal ships.
Contractors required to deliver BIM on a project without in-house capability
Engineering consultancies absorbing modeling peaks
Developers needing independent coordination review before construction
Architects whose consultants aren't coordinating with each other
Can you work inside our ACC or BIM 360 environment?
Yes. Working in the client's common data environment is preferred: it keeps version control in one place and removes file transfer overhead entirely.
We have a model but don't trust it. Can you audit it?
Yes. A model audit reports on structural integrity, naming compliance, LOD consistency and modeling errors, with a remediation estimate. It's usually cheaper than remodeling and we'll say so if it isn't.
How do you keep clash reports usable?
By tuning the rule sets and grouping clashes by cause rather than reporting every geometric intersection. A raw clash count of several thousand tells nobody anything; a grouped list of forty root causes is actionable.
Have a bim & revit modeling with clash detection project to scope?
A sketch, a photo, a spreadsheet: send what you have and we’ll take it from there.
